The question "soft starter or VFD" on an asynchronous motor is one of the most confused and most often wrongly decided topics in the field. Both devices give the motor a soft start, but one only manages the start while the other controls the motor speed from end to end. The wrong choice leads either to an unnecessarily expensive solution or to an incomplete investment that does not meet the need. The decision begins with a single question: do you only want a soft start from the motor, or do you also need to change its speed while it runs? In this article, HEM Motor compares soft starter and VFD in terms of cost, energy saving, starting current, torque, harmonics and maintenance, and explains which is right for which application with a clear decision logic.
The Core Difference: Soft Starter Manages the Start, VFD the Speed
A soft starter reduces starting current and mechanical shock by gradually raising the voltage applied to the motor during the start. Once the motor reaches rated speed, the soft starter is usually bypassed and the motor runs directly from the grid at full voltage. So the soft starter is only active during the start (and optionally the soft stop); it does not change the running speed.
A VFD (variable frequency drive), on the other hand, controls the motor speed from zero to rated speed by changing both the voltage and frequency applied to the motor. A VFD does not just provide a soft start; it continuously runs the motor at any speed you want. For this reason a VFD is not a starter but a speed control device, and the soft start is a by-product of it. We covered when a VFD is required and how it is selected in detail in our VFD with an asynchronous motor article.
The Critical Question: Just the Start, or Speed Control?
This is the axis on which the whole decision turns. If the motor will run at a constant speed and your only problem is softening the starting shock and current, a soft starter is the sufficient and economical solution. If your process requires continuously adjusting flow, pressure, speed or production rate, a VFD is essential. If softening a conveyor's start is enough, a soft starter; if a pump's flow must be continuously varied, a VFD is the right answer.
Decision Matrix: Soft Starter vs VFD Comparison
The table below compares the two solutions against the key criteria. This matrix lets you make a quick preliminary decision based on your application.
| Criterion | Soft Starter | VFD (Frequency Drive) |
|---|---|---|
| Core function | Soft start / stop | Full speed control |
| Changes running speed? | No | Yes |
| Starting current | ~2-4 x In | ~1-1.5 x In |
| Starting torque control | Limited | Full (high breakaway torque) |
| Energy saving (pump/fan) | None (fixed speed) | High (affinity law) |
| Initial cost | Low | High |
| Panel footprint | Compact | Larger |
| Harmonics | Very low (none after bypass) | Present (filter may be needed) |
| Heating (in motor) | Low | Extra heating at low speed |
As the table shows, a VFD offers more capability but is more expensive, larger and a solution that must be managed more carefully for harmonics. A soft starter is simple, cheap and harmonic-free, but it offers no speed control. You can also find the starting logic compared with direct on line (DOL) in our star-delta vs soft starter article.
Starting Current and Torque: The Behaviour of Each Method
In direct on line starting an asynchronous motor draws 6-8 times the rated current, which causes voltage dips on the grid and mechanical shock. A soft starter typically reduces this current to 2-4 times; because it raises the voltage gradually, the torque also rises gradually. However, since the soft starter manages torque via voltage, it can be limiting on loads that need high starting torque.
A VFD, on the other hand, can reduce the starting current to 1-1.5 times the rated current and at the same time produce high torque at low speed. This makes the VFD advantageous on loads requiring high breakaway torque, such as conveyors, crushers and extruders. In vector control mode a VFD can deliver full torque even at very low speeds; we covered the difference between scalar (V/f) and vector control in our scalar (V/f) and vector control article.
Energy Saving: The VFD's Strongest Argument
In pump and fan applications the VFD's biggest advantage is energy saving. According to the affinity law, when a pump or fan speed is reduced by 20%, the power consumption falls by roughly half. Adjusting flow by reducing speed rather than throttling a valve provides a large energy gain. A soft starter cannot provide this saving because the motor runs at fixed speed, at full revolutions, after the start.
For this reason, in variable-flow pump and fan applications the higher initial cost of a VFD is usually paid back quickly by energy saving. By contrast, in an application running continuously at full load and constant speed, the VFD's energy advantage disappears; in that case a soft starter is more sensible. We detailed how the real gain is calculated with the affinity law in our energy saving in pumps and fans with a VFD article.
Harmonics, Maintenance and Side Effects
Because a VFD is a power electronics device, it injects harmonic distortion into the grid; at high power a line reactor or harmonic filter may be needed. There is also a risk of voltage spikes (du/dt) reaching the motor winding and bearing currents in a VFD system; therefore shielded cable, correct grounding and, where needed, an insulated bearing are recommended.
- Harmonics: A VFD may need a filter/reactor; a soft starter produces no harmonics after bypass.
- Bearing current: Shaft grounding and an insulated bearing come into play in a VFD system.
- Cooling: If continuous torque is produced at low speed with a VFD, an external forced fan may be needed.
- Maintenance: A soft starter is loss-free in operation because it is bypassed; a VFD is always active and its cooling must be monitored.
We detailed the grounding and EMC rules in a VFD system in our grounding and EMC in a VFD system article, and the harmonic-induced extra heating in our VFD and harmonic-induced heating article.
Which One for Which Application? A Practical Decision Guide
Summarised from field experience:
- Choose a soft starter: Constant-speed pump, fan, compressor, conveyor; only starting shock and current are the issue; budget and panel space are limited.
- Choose a VFD: Pump-fan needing variable flow/pressure; a process needing speed control; a load needing high starting torque; a high energy-saving target.
- Slip-ring motor / special starter: Loads such as very high inertia mills and crushers should be assessed separately.
The decision always starts from the application, not the device. First clarify what the load needs; the soft starter vs VFD question then answers itself.
Real Application Scenarios
To make the theoretical comparison concrete, let us look at a few typical field scenarios. These examples show how the same question is answered differently on different loads.
- Constant-flow circulation pump: The pump always runs at the same flow and the only issue is the starting shock. Here a soft starter is the right solution; a VFD brings unnecessary cost and harmonics.
- Air-handling unit fan (variable flow): The fan runs at different flows through the day. Reducing speed with a VFD provides both comfort and large energy saving; a soft starter cannot meet this need.
- Conveyor line: A soft start prevents material from slipping. If speed is fixed a soft starter is enough; but if line speed changes with the product a VFD is needed.
- Screw compressor: If load is constant a soft starter may be enough; but with variable air demand, speed control via a VFD provides serious energy saving.
- Crusher / extruder: If high starting torque and jam resistance are needed, the VFD's ability to deliver full torque at low speed becomes decisive.
As seen, the same starting need requires completely different solutions depending on the character of the load. For this reason, before deciding, it is essential to clarify the load's torque-speed curve, flow-pressure variability and duty profile.
Total Cost of Ownership: Beyond the Initial Price
In comparing a soft starter with a VFD, looking only at the purchase price is misleading. The right decision includes the total cost and gain the device brings over its life. A soft starter has a low initial cost and is compact; it is loss-free in operation because it is bypassed. A VFD, although it has a higher initial cost, closes this gap quickly through energy saving in a suitable pump-fan application and keeps producing savings over its life.
On the other hand, a VFD has hidden costs too: a harmonic filter, shielded cable, correct grounding, an insulated bearing where needed and an external cooling fan at low speed. If these items are not accounted for, a VFD solution that looks cheap at first can bring unexpected costs later. For this reason, when deciding, the whole system surrounding the device (panel, cable, protection, cooling) must be evaluated as a whole. As HEM Motor, by making the motor selection within this system integrity, we eliminate later surprises from the start.
Frequently Asked Questions
Can I adjust the motor speed with a soft starter?
No. A soft starter only manages the voltage during the start (and optionally the stop); after the start the motor runs at full speed, at constant speed. If you want to change the running speed you need a VFD (variable frequency drive). This is the most fundamental difference between the two devices.
Is a VFD always better?
No. A VFD offers more capability but is more expensive, requires more panel space and needs harmonic management. In an application running at constant speed and continuous full load, a VFD has no energy advantage; in that case a soft starter is a more economical and simpler solution. The right choice depends on the application.
Which one harms the grid less?
In terms of starting current the VFD draws the lowest current. However, during operation, in terms of harmonics a soft starter (when running bypassed) injects no harmonics into the grid, while a VFD produces harmonics and may need a filter. So the VFD is advantageous at start, and the soft starter is advantageous for harmonics in continuous operation.
The right answer to the soft starter vs VFD question lies in your application, not in the device. If a soft start is enough, a soft starter; if speed control and energy saving are needed, a VFD is the right choice. As HEM Motor, we recommend the right starting solution by assessing your motor, your load and your process together, and supply the matched motor quickly from stock. Request a quote for the starting decision and motor selection best suited to your application; with manufacturer stock advantage and technical support, we are at your side.
